Albedo Radiation Sensor, 285-3000nm

0 review(s) | Add your review

SKU: SUCH-RS-ALB

$649.99

● 285-3000 nm spectral range ● RS485 signal output ● -40°C to +85°C operating temperature ● IP67 protection level

Qty:

🚚 Free shipping

🕒 Delivery date: 6-12 days

🔁 30-day Returns

Overview
Specs
Application
FAQ
Reviews

Overview

Albedo radiation sensor is designed for precise shortwave reflectance measurement, complying with ISO 9060 and WMO standards for professional environmental and meteorological applications. It delivers high-sensitivity detection within the 0.285–3 μm band, ensuring accurate albedo and solar radiation analysis. Built with robust IP67 protection, RS485 signal output, and a wide operating temperature range of –40°C to +85°C, the sensor offers stable, reliable performance in harsh outdoor environments.

Albedo radiation sensor feature

Feature

ISO & WMO Compliance: Albedo radiation sensor meets ISO 9060 and WMO standards for professional-grade solar radiation measurement.
Wide Spectral Range: Covers 0.285–3 μm for precise shortwave solar irradiance detection.
Accurate Albedo Measurement: Measures reflectance within the 0.285–3 μm band for reliable albedo analysis.
High Sensitivity: Provides strong responsiveness and stable output for accurate radiation monitoring.

Specs

Response Time (95%)	13 s
Thermal Radiation Zero Drift	±10 W/m²
Temperature Zero Drift	±3 W/m²
Nonlinearity	±1.5%
Instability	±1%
Directional Response	±18 W/m²
Spectral Error	±3%
Temperature Response (−10°C to +40°C)	3%
Tilt Error	±1%
Spectral Range	285-3000 nm
Daily Accuracy	<5%
Resolution	1 W/m²
Sensitivity	7-14 μV/(W·m⁻²)
Signal Output	Digital: RS485
Protection Level	IP67
Product Size	16011020 mm
Product Weight	3 kg
Operating Temperature	-40°C to +85°C
Operating Humidity	0-100% RH
Cable Length	Standard 1.5 m (customizable)
Included Accessories	Protective radiation shield, data cable, user manual, packaging box

Application

Agricultural and Forest Ecology Research

Soil Water Evaporation and Total Energy Loss Calculation

Crop Disaster Prevention

FAQ

Q1: What does "Albedo" mean? ❯

Albedo refers to the reflectivity of a surface, expressed as the ratio of reflected solar radiation to the incoming solar radiation. It indicates how much sunlight a surface reflects rather than absorbs.

Q2: What does an Albedo Radiation Sensor measure? ❯

It measures upward (reflected) shortwave radiation and compares it with downward (incoming) shortwave radiation, allowing accurate calculation of surface albedo.

Q3: How does an albedo sensor differ from a regular pyranometer? ❯

A standard pyranometer measures only incoming shortwave radiation. An albedo sensor uses two matched detectors (one upward-facing and one downward-facing) to measure both incoming and reflected radiation for accurate reflectance calculation.
